Introduction:
The Omunuo geothermal special ultra-thin floor mat is an excellent heating system. It is easy to install and is suitable for all kinds of floor decoration materials, such as concrete floor, wood floor, old tile floor and terrazzo floor.
It is mainly installed in the ceramic tile adhesive and has little effect on the elevation of the ground.
The eubno geothermal special ultra-thin floor mat can also be directly laid on the original ground, without any other treatment of the original ground.
In addition, the very thin preheating layer can enable you to get the desired ground temperature within 20 ~ 30min after starting the system, so this heating system is the best choice for the bathroom and other home places. Suitable for integral heating, comfortable heating, wall heating, height strict requirements and secondary decoration.
Product Structure and Technical Parameters
Fiberglass mesh:
300g/㎡ double-sided adhesive tape
Outside diameter of cable:
2.5mm
Thickness:
4~4.5mm
Cable insulation layer:
Teflon(150°C FEP)
Power per unit area:
100W/㎡ 150W/㎡
Cable sheath:
Teflon(150°C FEP)
Voltage:
220V(customizable)
Cable shield:
Aluminum foil + copper wire
Conductor:
2*2m
Maximum operating temperature:
120°C
Cable structure:
single conductor
Warranty period:
10 years
Product certification: UL
Omunuo OTVF-100series heating floor MATS
(Single Conductor 100W/㎡)
Introduction:
The Omunuo geothermal special ultra-thin floor mat is an excellent heating system. It is easy to install and is suitable for all kinds of floor decoration materials, such as concrete floor, wood floor, old tile floor and terrazzo floor.
It is mainly installed in the ceramic tile adhesive and has little effect on the elevation of the ground. The eubno geothermal special ultra-thin floor mat can also be directly laid on the original ground, without any other treatment of the original ground. In addition, the very thin preheating layer can enable you to get the desired ground temperature within 20 ~ 30min after starting the system, so this heating system is the best choice for the bathroom and other home places. Suitable for integral heating, comfortable heating, wall heating, height strict requirements and secondary decoration.
Product Structure and Technical Parameters
Fiberglass mesh:
300g/㎡ double-sided adhesive tape
Outside diameter of cable:
3mm
Thickness:
3~5.5mm
Cable insulation layer:
Teflon(150°C FEP)
Power per unit area:
150W/㎡
Cable sheath:
Teflon(150°C FEP)
Voltage:
220V(customizable)
Cable shield:
Aluminum foil + copper wire
Conductor:
1*2m
Maximum operating temperature:
120°C
Cable structure:
double conductor
Warranty period:
10 years
Product certification: UL CE
Omunuo OTIF-100series heating floor MATS
(Double Conductor 100W/㎡)
